Field Control Processor 270(FCP270)
The Field Control Processor 270 is a distributed,optionally fault-tolerant,field-mounted controller that
performs process control and alarming functions according to a user-defined control strategy
FEATURES
Performs regulatory,logic,timing,and sequentialcontrol together with connected FieldbusModules(FBMs)
Performs data acquisition and alarm detectionand notification
Supports up to 32 200 Series FBMs-referring toboth Compact or standard types
Supports up to 128 200 Series FBMs(Compactor standard)with a Fieldbus Expansion Module100(FEM100)
Supports up to 64 of the 100 Series FBMs
No Fieldbus Communication Module is required
Connects to The MESH control network viastandard fiber optic 100 Mbps Ethernet
Uses a rugged,die cast aluminum housing formounting in a non-vented field enclosure
Can operate in Class G3 harsh environments
Is CE certified for field mounting in enclosures
Supports both the 2 Mbps or 268 Kbps HDLC fieldbuses simultaneously with the FBI200 or
FBI100,allowing connections to both 200 Series and 100 Series FBMs(affects the total number of each type of FBM supported).
Offers unique,patented,fault-tolerant operation using two control modules to greatly improve reliability relative to other process controllers
Uses versatile control algorithms and a wide variety of FBMs to provide control capabilities for a broad range of process applications
Remote installation
The FCP270 flattens Foxboro Evo and simplifies the process automation system architecture,requiring only field cabinets and workstation Ethernet switches.About MESH Control Network Architecture
The field installed FCP270 is a highly distributed control network in which the controllers are closely aligned with the specific process units installed with their I/O and actual controlled devices.The coordination processing unit between the two is carried out through a 100 Mbps optical fiber
Ethernet.
The FCP270 is packaged in a robust die cast aluminum housing due to its efficient design.The FCP270 is CE certified,and it can install cabinets without expensive special equipment to prevent electronic emissions.This FCP270 can be installed in G3 level harsh environments.
Enhanced reliability(fault tolerance)
Unique and patented fault-tolerant operation FCP270 compared to other process controllers.The fault-tolerant version of FCP270 consists of two modules in parallel,with two Ethernet connection control networks to MESH.Two FCP270 modules are combined as a fault-tolerant pair to provide continuous operation of controller failures that occur within one of the pair of modules in almost any hardware situation.While both modules receive and process information,the fault is caused by the module itself.One of the important methods of fault detection is communication comparison
Messages at the external interface of the module.
Only in two cases will the message leave the message that the controller agrees to send
Other relevant models:
FBM01 P0400DA 0-20MA input 8AI
FBM02 P0400YC Thermocouple/millivolt input 8AI
FBM03 P0400YD thermal resistance input (three wire/four wire system) 8AI
FBM04 P0400YE 0-20MA input/output 4AI/4AO
FBM05 P0400YF Redundant 0-20MA Input/Output 4AI/4AO
FBM06 P0400YG frequency input/0-20MA output 4PI/4AO
FBM07 P0400YH contact/DC voltage input 16DI
FBM08 DM400YJ (P0400YJ) 120VAC AC status input 16DI
FBM09 CM400YK (P0400YK) contact/DC voltage input/contact output 8DI/8DO
FBM10 DM400YL (P0400YL) 120VAC AC state input/contact output (2A) 8DI/8DO
FBM11 CM400YM (P0400YM) 240VAC AC state input/contact output (1A) 8DI/8DO
FBM12 CM400YN (P0400YN) contact/DC voltage input extension 16DI
FBM13 DM400YP (P0400YP) 120VAC AC state input extension 16DI
FBM14 CM400YQ (P0400YQ) contact/DC voltage input/contact output extension 8DI/8DO
FBM15 DM400YR (P0400YR) 120VAC AC state input/contact output extension (2A) 8DI/8DO
FBM16 CM400YS (P0400YS) 240VAC AC state input/contact output extension (1A) 8DI/8DO
FBM17 DM400YT (P0400YT) 0-10V DC voltage/contact input/output 4AI/2AO/4DI/4DO
FBM18 P0400YV transmitter input 8AI
FBM20 CM700QV (P0700QV) 240VAC AC status input 16DI
FBM21 CM700TW (P0700TW) 240VAC AC state input extension 16DI
FBM22 P0900HS manual and automatic operation station interface 1AI/1AO
FBM24 DM900HT (P0900HT) point/125V DC voltage input 16DI
FBM25 DM900NX (P0900NX) point/125V DC voltage input extension 16DI
FBM26 DM900HU (P0900HU) contact/125V DC voltage input/output 8DI/8DO
FBM27 DM900NY (P0900NY) contact/125V DC voltage input/output extension 8DI/8DO
FBM39 P0902UT intelligent transmitter input/0-20MA output 4AI/4AO
FBM41 P0902XA contact input/contact output (2.25A) 8DI/8DO
FBM42 P0902XB contact input/contact output (2.25A) extension 8DI/8DO
FBM46 P0950DA redundant intelligent transmitter input/0-20MA output 4AI/4AO
FBM201 P0914SQ DIN mounting 0-20MA input 8AI
FBM202 P0926EQ (P0914ST) DIN mounted thermocouple/millivolt input 8AI
IPM03A P0904HB Backup AC/DC Power Supply Assembly
IPM06A CM902WX AC/DC Memory Backup Power Supply Assembly
FBM201b P0922YH 8-channel 0-100mV input interface assembly
FBM201c P0922YJ 8-channel 0-5V input interface assembly
FBM201d P0922YK 8-channel 0-10V input interface assembly
FBM202 P0926EQ 8-channel thermocouple/millivolt input interface assembly
FBM203 P0914SV 8-channel 0-320 thermal resistance input interface assembly
FBM203b P0922UA 8-channel 0-640 thermal resistor input interface assembly
FBM203c P0922UD 8-channel 0-30 thermal resistance input interface assembly
FBM204 P0914SY 8-channel 0-20mA input/output interface assembly
FBM205 P0914XG redundant 8-channel 0-20mA input/output interface assembly
FBM206 P0916CQ 8-channel pulse input interface assembly
FBM207 P0914TD 16-channel voltage monitoring input interface assembly (optional redundancy)
FBM207b P0914WH 16-channel 24Vdc contact input interface assembly (optional redundancy)
FBM207c P0917GY 16-channel 48Vdc contact input interface assembly (optional redundancy)
FBM208 P0914TB 4-channel 0-20mA input/4-channel 0-20mA output assembly
FBM211 P0914TN 16-channel 0-20mA input interface assembly FBM212 module
FBM213 P0914XL 14-channel thermocouple input interface assembly FBM213 module
FBM214 P0914XN 8-channel thermal resistance input interface assembly FBM214 module
P0914XQ 8-channel HART communication input interface assembly
FBM215 P0922VU 8-channel HART communication output interface assembly
FBM216 P0922VV redundant 8-channel 0-20mA/HART input interface assembly
FBM217 P0914TR 32 channel discrete input interface assembly (optional redundancy)
FBM218 P0922VW redundant 8-channel 0-20mA/HART output interface assembly
FBM219 P0916RH 24-channel voltage monitoring input, 8-channel discrete output interface assembly
FBM220 P0917HA 1-channel H1 FOUNDATION fieldbus interface assembly
FBM221 P0917HB 4-channel H1 FOUNDATION fieldbus interface assembly
FBM223 P0917HD 2-channel PROFIBUS-DP fieldbus interface assembly
FBM224 P0926GG 4-port RS-232, RS-422, or RS-485 with Modbus components
FBM237 P0914XS redundant 8-channel 0-20mA input interface assembly
FBM241 P0914TG 8-channel voltage monitoring input, 8-channel discrete output (external source)
FBM241b P0914WK 8-channel voltage monitoring input, 8-channel discrete output (internal source)
FBM214c P0914WM 8-channel contact input, 8-channel discrete output (external source) assembly
FBM214d P0914WP 8-channel contact input, 8-channel discrete output (internal source) assembly
FBM240 P0917GZ redundant output interface assembly
FBM242 P0916TA 16-channel discrete output (external source) interface component (optional redundancy)
FBM243 P0914TK 8-channel bidirectional FoxCom dual baud rate intelligent device interface component
FBM246 P0914XN redundant 8-channel bidirectional FoxCom dual baud rate intelligent device component 2. Fieldbus communication component
FCM10E P0914YM (Converts 10 Mbps Ethernet signals to 2 Mbps signals for use with D-type rail mounted fieldbus components (paired redundant fieldbus use)
FCM10EF P0916CD (Converts 10 Mbps optical fiber signals to 2 Mbps signals for use with D-type rail mounted fieldbus components (paired redundancy)
