EL3020 ABB Gas analyzer
Brand ABB Color Standard Application Industrial height 240mm rated current 280mA
Protection level IP45 Suitable for motor power 86KW Application Site Power Industry BOM Number GJR2391500R1220 Power industry HIEE401782R0001 Part Number EL3020
Applicable pipe 2 Whether imported is weighing 8.7 kg can be sold nationwide
EL3020 ABB Gas analyzer
ABB gas analyzer EL3020 technical data
The ABB EL3020 analyzer uses an inflatable * climate radiation detector. The detector fill corresponds to the gas being measured, which means that the detector offers maximum sensitivity and high selectivity compared to other gas components in the sample.
ABB EL3020 infrared Gas Analyzer Product Features:
1, double-layer detector and optical coupler, good selectivity.
2. Low detection limit value
3. Corrosion-resistant materials are used in gas path (optional)
4. The sample gas chamber can be cleaned
5, electrical and physical characteristics: airtight isolation, can be purged, protection level IP65
6, heating type (optional)
7, EEx (p) explosion-proof, for zone 1 and zone 2
Product parameters:
Instrument main technical indicators
1. Analysis object: CO, CO2, NO, SO2, NH3, H2O, CH4 and other hydrocarbons.
2, Weight: about 15kg (1 infrared channel), about 21kg (2 infrared channels)
3, power consumption: single channel: about 40 VA, dual channel: about 70 VA
4, power supply: 100-240VAC±10%48-63HZ
5, linear error: ±0.5%FS
6, response time: <3 seconds
7, analog output: 0/2/4-20mA large load 750Ω
8. Measurement drift: ±1%FS/ week
9, large range: depending on the application
10, small range: CO: 0-10ppm CO2:0-5ppm
11, measuring range: 4 range automatic range switching
Application range of gas analysis instrument
An analytical instrument used to continuously measure the concentration of individual components in a gas or steam.
Combustible gases/air, or mixtures of gases and oxygen cannot be measured.
Gas analysis meters (EL3020 and EL3040) with stainless steel lines and fittings can be used to measure combustible gases and vapors in safe areas. Oxygen sensors and integrated gas analysis modules (available only in the EL3020) cannot be used in analytical instruments measuring combustible gases.
The Gas Analyzer with explosion-proof device (EL3040) meets the explosion-proof requirements of ll3G and can measure non-combustible gases and vapors in hazardous areas.
Performance test
EL3000 series gas analyzer
•Uras26 (sample composition CO, NO, SO2, CO2, N2O),
•Magnos206 (sample composition O2)
• Electrochemical oxygen sensor (sample composition O2)
IZE INDUSTRIES * Distributed, commonly used ABB gas analyzer models:
ABB gas analyzer EL3020
ABB gas analyzer EL3040
ABB Infrared Photometer Uras26
ABB Oxygen Analyzer Magnos206
ABB Trace Oxygen Analyzer ZO23
ABB Thermal Conductivity Analyzer Caldos27
